Product Name

Product Name: 4G Body Camera

Model No.: BC602

Key Features

High quality recording: Record resolution up to 2650x1440 (1440P).



• Live streaming: The camera has the ability to stream in real time via 4G or WiFi connectivity. The operator can also understand the wearer's positon by built-in GPS. Alternatively, camera wearer can send an alert back to the control centre with their live video, GPS location details.




• 12-Hour full shift battery life: replaceable battery and up to 12-hour working life ensures your camera lasts a whole shift which is critical to ensure recording capability.



• Record file protection: Using AES256 encryption technology, the record file in the camera will be safe and protected from unauthorized access.

• Interphone function: By pressing the PTT button on the camera, the camera can work like a walkie talkie and talk to other cameras anywhere in the world via 4G or Wifi connectivity.



• Rugged and waterproof: With rugged design and IP66 waterproof, the camera stands up to the most extreme environments. The camera can survive from drops & impact . It can aslo be used in the rain, dust and extreme temperatures.




Specification

OS

OS

Linux 4.19.63

Booting time

< 6 s

Video

Video input

1x digital built-in Camera, available for external camera up to 1080p30

Video output

2 inch IPS LCD screen (480x360)

Recording resolution

30fps @(720p/1080p/1296p /1440p) ; optional HDR1080p30 with HDR Sensor

Record mode

Record audio and video synchronously

Compression

H.264 / H.265 for Video, and AAC for audio

Audio

Audio input

1x MIC input

Audio output

1x head phone interface

Record mode

Support to record audio only into .wav file

Video process

Live streaming

720p/ 1080p (only for 4G device)

Photograph

2M, 16M, 32M, 64M

Snap

Support snapping during recordingthe photo resolution base on recordingresolution

Storage

Built in 32GB TF card (available for 32128GB)

Light source

Flash light

To increase brightness when recording or taking a photo

Laser

Fix the view when you record (optional)

IR

Up to 10 Meters with Visible shape image at night

Two way radio

Talk back

Support two way radio between different devices(only for 4G device)

Talk back with platform

Support two way radio between device and platform(only for 4G device)

Lens

Lens’s angle

118° (HOV), 130° (FOV)

Alarm

Alarm input

Support alarm input and the alarm can be show in platform

Interface

USB

Type C 1x USB2.0, for charging, firmware updating, connecting to PC etc

Network

Protocol

TCP/IP

4G

Optional, built in 4G module(WCDMA/FDD-LTE/TDD-LTE) for live view

Wi-Fi

Optional, support Wi-Fi in AP or Client mode (to access internet via Wireless Router), for live view or uploading recorded files directly into cloud server

Dock Station

Connect to GigE dock station and upload recorded files directly into cloud server

GPS

GPS

Optional module for GPS/BDS/GLONASS, to record coordinates and speed

Firmware

OSD

Display and burn in text of date, time, officer ID, geo-tags, speed

Overwrite

Support overwrite or non-overwrite mode

Play back

Support play back, file listed by time and alarm

Pre-Rec/post-Rec

Maximum 5 min pre-recording and 5 min post-recording

De-Warp

Support de-Warp to correct distorted image

Safe mode

Need password to enter Setting or Playback in safe mode

Record encryption

Support Record encryption, encrypted video can be played in special player

Log

Record power ON/Off, setting change, start record, alarm etc.

Software

hPlayer

Player software, play multiple cameras together, can also play the encrypted file

CMSV6

Support live view/live tracking/historical track(4G device only)

Upgrade

Firmware maintain

Firmware can be upgraded through USB/Network

Working condition

Temperature

-30~65

Humidity

40%~80%

Other

Time

synchronize with GPS, internet, PC

Factory Default

Can set to default factory setting

Indicators

Power, Record, Snap, Audio record, Charging, Charging Complete

Battery

2700mAh battery, built-in 60mAh battery to ensure continuous power during replacement.

12 hours continuous recording @1920x1080, standby up to 41h, live view streaming via 4G up to 6h.

Waterproof

IP56

Size

88.4mm×59mm×34.3mm

Weight

About 165g
